Description: Scuppers are used to provide an outlet through parapet walls or gravel stops on flat and built-up roofs to allow drainage of excess water. They can be used in conjunction with gutters and downspouts to divert the flow to the desired location.

Why is it called a scupper?

Scupper Has Military Origins All efforts to figure out where this verb came from have been defeated, including attempts to connect it to the noun scupper, a 500-year-old word for a drain opening in the side of a ship.

What are roof scuppers?

This drainage system looks like an opening in the parapet or wall of your flat commercial roof. Some scuppers have a simple spout that pours water down the side of your building, while others are connected to downspouts that send the water directly to the ground level.

Where do you find scuppers?

Scuppers are installed at the perimeter of the roof area and can be located at openings in parapet walls and/or openings in the perimeter metal. Scuppers can be used as primary or secondary (overflow) drainage. Proper flashing details are required at scuppers to prevent moisture infiltration into the roof system.

What do scuppers do?

What Do Scupper Plugs Do? Scupper plugs give you the ability to cover the self-bailing drain holes in the hull of a sit-on-top kayak. This helps you achieve a drier ride by preventing water from coming up through the scupper holes. Naturally, most sit on top kayaks collect a small amount of water while you paddle.

How many scupper plugs kayak?

The average kayak has 6-8 scupper holes in various sections of the boat. Gene likes to keep the rear holes plugged because that’s where most of the weight is carried. Plugging them helps give the boat a bit of lift out of the water. It also keeps that area drier.

What is the difference between scupper and scuttle?

There scupper is defined as “an opening cut through the bulwarks of a ship so that water falling on deck may flow overboard” while scuttle means “sink or attempt to sink [a ship] by making holes through the bottom” and also “destroy, wreck or scrap.”

Is a scupper a drain?

Roof scuppers are not the same as roof drains. Roof drains channel water through the deck of the roof into a piping system that carries water away, while a scupper allows water to drain through an opening in the side of the roof edge.

How does flat roof drain?

What do Drainage Systems do? A low-slope roof tilts slightly downhill from its center or from one side, so water rolls off to parapet scuppers and down the hopper (downspout). The scuppers are the openings in the outside walls, specifically designed to allow water, but not debris, to wash off your roof.

Do you need an overflow roof drain?

Overflow drains, located 2 inches (51 mm) above the roof drain inlet, are required by Section 1506.3 where parapets or other conditions will cause ponding if the roof drain is inoperative. … The lower edge of the overflow scupper opening shall be 2 inches (51 mm) above the roof drain.

Article first time published on

Do you need guttering on a flat roof?

Most modern flat roofs are covered by a membrane that prevents water leaking into your property. But if your roof has a slight slope it will need gutters to ensure proper drainage.

Why is it called a roof cricket?

The term “cricket” originates from the construction industry. It describes a wooden, framed-out, triangular structure that’s installed over top of the already existing flat or pitched roof. It’s designed to direct water away from areas of the roof that are susceptible to leaks because of their sharp change of angles.

How do you calculate scupper size?

To adjust this table for other than a 5-inch design rain fall rate, multiply the square footage on the table by 5 then divide by the local design rain fall rate. Example: For 4 inches of design rainfall rate, a 4-inch long scupper with a 1-inch head would accommodate 287 square feet. (230 x 5) ÷4 = 287.

Why do kayaks have drain plugs?

Water inside the kayak not only created a pool of water to sit in but also additional weight which made the kayak heavier and harder to move through the water. … A sit-in kayak will have a rear drain plug which allows water to be removed when back on shore.

Do you plug scupper holes?

If you’re kayaking with a heavy load, you should plug in your scupper plugs before paddling. The extra weight will submerge your kayak further down, and water will rise from the holes. The scupper plugs will protect you from capsizing. In the summer, covering the scupper holes might not be a priority.

Can a sit-on-top kayak sink?

With scupper holes (holes in the kayak that allow any water to drain out) and nowhere for water to collect, a sit-on-top kayak won’t sink when capsized.

What are scupper plugs for?

They are a safety feature of sit-on-top kayaks, but their purpose is to plug up the scupper drain hole. Designed only to fit the scupper holes, the plugs fill those openings to keep water from getting into the kayak during those times that your boat takes on extra water.

What is a scupper drain airplane?

Scupper. A recess around the filer neck of an aircraft fuel tank. Any fuel spilled when the tank is being serviced collects in the scupper and drains to the ground through a drain line rather than flowing into the aircraft structure.

Are kayaks supposed to have holes in the bottom?

They actually release water that could into your craft via waves or sloppy paddling, so they are helping to keep you afloat. Don’t worry, these holes at the bottom of your boat won’t leave you sunk. Most kayaks will have about four scupper holes as this is thought to be the safest amount.

Why are there holes in my fishing kayak?

Scuppers or scupper holes are openings found on the side walls of kayaks or any open-air boat (structure) to help drain off water. Typically, scupper holes are positioned at or near the ground level, allowing water or liquids to flow off to the side of the kayak, instead of pooling in the side walls of the craft.

Should you wax your kayak?

Wax On, Wax Off – Why Waxing Your Kayak Is Important Applying a kayak wax to your vessel can give it that extra layer of protection against damage. This means it could boost the durability of the hull, helping to protect it from the sun’s harmful rays, as well as scratches or dents.

Can you install gutters on a flat roof?

As you may know, rain gutters are the most common drainage system for any type of roof because they have a lot of benefits. … Gutters are pipes that are attached to the edges of the roof. It is as simple as that. Besides, they can be installed without having to modify the roof in any way.

How many drains does a flat roof need?

It is important to remember that no roof area should ever have less than two roof drains. Size and placement of rooftop equipment may necessitate additional roof drains. Consideration should also be given to local codes whish may require separate overflow drain systems.

Where does rain go on a flat roof?

Gutters are the most commonly used, and most cost-effective drainage solution for flat roofs. They catch rainwater as it rolls off the edge of the roof and divert the water into a downspout that dispenses it a safe distance from the foundation of the building.

What is a scupper pipe?

Definition of scupper pipe : a drainpipe from a deckhouse roof to the scuppers or from the deck to an opening in the side.

What is a flat roof drain called?

Gutters. Gutters are the most commonly used drainage system when it comes to flat roofs. Just like the gutters installed on sloped roofs, these marvels catch rainwater and divert it into a downspout, which carries it away from the foundation.

How do scupper drains work?

In short, a scupper is a detail that provides drainage to a roof system by allowing the water runoff from the roof to exit the roof through a metal edge, parapet wall or through the deck into a downspout or leader not run through the interior of the building.

Do roof drains need to be insulated?

Insulation should be provided on all piping, especially on commercial projects but also on residential jobs. … Storm water piping is also susceptible to condensation and should be insulated from the roof drain bowl to a point where the piping turns from horizontal to vertical.

Where should a roof drain be placed?

Location – Drains SHOULD NOT be next to other rooftop objects like A/C units, vent pipes, or skylights. Level – Drains SHOULD always be installed at the lowest level of the roof surface. Strainers/Domes – Drain strainers SHOULD have holes or openings large enough for small debris to pass through.

Where are roof drains required?

Where roof drains are required, secondary (emergency overflow) roof drains or scuppers shall be provided where the roof perimeter construction extends above the roof in such a manner that water will be entrapped if the primary drains allow buildup for any reason.

Do flat roofs leak more?

Sometimes water pools on the roof, and this will eventually cause leaks. That’s when flat roof repair becomes necessary. While flat roofs are a little more prone to leaks, they don’t always develop them or develop them about as often as other roof types.
