Substrate is a general term that means any surface below another surface but which, in the home remodeling world, most often refers to the stabilizing layer of material directly beneath the finish floor.

What is the difference between a substrate and an underlayment?

6. Subfloor/Underlayment Combination – A surface that must meet structural requirements and have a smooth surface suitable for the floor covering. 7. Substrate – The smooth surface prepared to accept the resilient floor covering, such as concrete, underlayment or existing resilient floor covering.

What is floor underlayment used for?

Underlay or flooring underlayment is a thin layer of material such as fiber, felt, rubber or foam. The thin layer of material helps cushion, sound absorption, insulation and reduce wear with your flooring.

What can I use for floor sheathing?

Plywood is considered the most popular material used for subflooring, it has been used since the 1950s and remains one of the top choices for contractors. Standard plywood works perfectly fine as a subflooring material, but the best option is ¾” tongue-and-groove plywood subflooring.

What are the layers of a floor called?

A general floor typically has four layers: floor covering, underlayment, subfloor, and joists. The first layer called floor covering is something that most homeowners are aware of. It is normally what they look for when they’re dealing with a Maryland flooring company or any local contractor.

What goes on top of subfloor?

Underlayment: Some types of flooring can be installed directly on top of the subfloor, such as vinyl flooring. Other types need a middle layer, called underlayment, such as laminate,carpet and tile.

Do I need a subfloor over concrete?

If you don’t plan to use the space, there is no need for a subfloor or floor covering. Concrete or tile-over-concrete are acceptable floors for uninhabited basements. But to install any kind of floor covering—engineered wood, laminate, carpeting—basement subflooring is highly required.

Can sheathing plywood be used for subfloor?

Like Sturd-I-Floor, Rated Sheathing may be plywood or OSB. When used as a subfloor, Rated Sheathing typically requires installation of an additional layer of underlayment on top of it before finish flooring can be applied. The underlayment requirements vary depending on the finish flooring.

Can I use regular plywood for subfloor?

Standard plywood can be used for subfloors, but it is more common to use tongue-and-groove sheets that interlock along the edges. The recommended thickness of the plywood subfloor is governed by the spacing of the joists.

What plywood do you use for subfloor?

Standard plywood can be used for subfloors, but a better material is 3/4-inch tongue-and-groove plywood subflooring. The tongue-and-groove edges interlock to resist movement along the panel edges and create an overall stiffer floor.

Article first time published on

What is the difference between underlayment and plywood?

Often, the terms “subfloor” and “underlayment” are used interchangeably. Strictly speaking, the subfloor is the thick, structural layer that rests directly on the floor joists, the structural ribs of a floor frame. Underlayment is a thinner material that lies over the subfloor. … Plywood is only one type of underlayment.

What happens if you don't put underlayment under laminate flooring?

If the subfloor in your home or property is uneven, then your laminate floor could move and shift if it doesn’t have an underlayment for support. As a result, the floor will be more prone to wear-and-tear and could even warp. The more stability, the less likely you’ll have to pay out of pocket for costly repairs.

What type of flooring does not need underlayment?

However, you’ll want to use one in every other application including covering existing hardwood floors, vinyl flooring that isn’t cushioned, and concrete floors. You also do not need an underlayment if your vinyl plank flooring has underlayment installed, however, you may need a vapor barrier.

How do you layer a subfloor?

Fasten your first layer plywood subfloor as you normally should. The second (top) layer of plywood joints should not coincide with the joists and the second layer should not be fastened to the joists. Article quote from – Position of Underlayment to Prevent Cracked Tile and Grout By Frank Woeste and Peter A.

What is the wood under floor called?

The subfloor is the bottom most structure of the floor. It provides a flat and stable surface and supports the actual floor. Underlayment is different from the subfloor in that it rests between the subfloor and the actual floor.

What underlayment should I use on concrete?

With a concrete subfloor, you will need an underlayment that acts as a vapor barrier in order to prevent moisture from penetrating through to your laminate installation. The normal choice is a thin foam pad material made of polyethylene or polypropylene, which rolls out in sheets.

What do you use for subfloor on concrete?

To install a floated subfloor system, first place a layer of plywood subfloor panels with the edges parallel to the wall. Use a ¾” spacer between the plywood and the wall and a 1/8” spacer between panels. Next, lay a second layer of plywood at a 45-degree angle to the first layer.

Can you put wood flooring on cement?

If you have a concrete slab main floor or basement, you may be wondering if it’s possible to install hardwood flooring directly on top of the concrete. The short answer is yes.

Can I put new subfloor over old subfloor?

One of the benefits of removing the old flooring is it allows you the chance to fix any loose subflooring or squeaks by re-securing the main subfloor to the floor joists prior to installing the new flooring. With all that being said though the answer is YES you can install New Wood Flooring over the old.

Should I screw or nail subfloor?

Using code-approved screws rather than nails is the best option for avoiding movement. If using nails for subfloor installation, stick with ring-shank nails; smooth nails may withdraw easier, leading to squeaks.

Do I need 2 layers of subfloor?

That’s the usual approach. Almost no one puts down double-thick subfloor in residential applications (for cost and handling reasons), and both layers need to be fastened to joists. Only thin underlayment can be fastened just to the subfloor.

Do you need tongue and groove for subfloor?

For subflooring, you use tongue and groove plywood. The tongue and groove are only along the 8 foot edges. On the four foot edges, your seams will fall on joist tops, so no need for tongue and groove.

Is it better to use OSB or plywood for subfloor?

The National Tile Contractors Association and the Resilient Floor Covering Institute both recommend plywood for subflooring and underlayment, because it doesn’t have the risk of swollen edges that OSB does. Plywood also has a slight advantage in stiffness, which means that subflooring panels need not be quite as thick.

How thick is subfloor in a house?

Typically made of plywood or OSB and ranging in thickness from 19/32″ to 1 1/8″ thick, the subfloor is truly structural, second only to joists in this respect. Subfloor holds up all of the above layers of flooring, as well as everything in your house, including people, dogs, cats, pianos, furniture.

What's the difference between sheathing and subfloor?

Plywood sheathing is typically more expensive than OSB and is constructed using plies. The plies are constructed when sheets of veneer are cross-laminated and glued together using a hot-press. … Sub-floors serve as structural platforms for your plywood underlayment and finished flooring.

How thick should subfloor plywood be?

The minimum thickness of plywood for subflooring is about 5/8 inch. Since it does not hold fasteners as well as plywood, OSB must be a little thicker, or at least 23/32 inch. There are several factors that determine what subfloor thickness is optimal for added benefits like insulation.

Is MDF good for subfloor?

ProsConsCapable of withstanding humidity more than wood materialPotentially toxic dust

Which is stronger OSB or plywood?

OSB and plywood offer similar (and sufficient) performance in terms of strength and functionality, though plywood is about 7% stronger. … Plywood will absorb moisture quicker than OSB, but consequently it will also dry quicker.

How much does subfloor cost?

The national average materials cost to install a subfloor is $3.05 per square foot, with a range between $2.85 to $3.25. The total price for labor and materials per square foot is $12.20, coming in between $8.27 to $16.12. A typical 300 square foot project costs $3,659.05, with a range of $2,481.75 to $4,836.34.

Does it matter what underlayment you use for laminate flooring?

Yes. Underlayment for laminate flooring provides proper support, stability, noise reduction and helps the click lock system to provide a structurally sound floor.

Can I install laminate without underlay?

If you are installing the laminate flooring in an area that receives little attention such as a mudroom or laundry room, and you simply need to quickly install cheap flooring, laminate flooring can be installed without underlayment. The subfloor must be perfectly flat and featureless: no nails, screws, bumps, or dips.
